The Response of the UMG96 RM-E can appear
as follows:
Description Hex Note
Device address 01 UMG 96RM, address= 1
Function 03
Byte meter 06
Data 00 00hex = 00dez
Data E6 E6hex = 230dez
Error Check (CRC) -
The L1-N voltage read by address 19000 is 230V.
Example: Reading the L1-N voltage
The L1-N voltage is saved in the measured value list
at address 19000. The L1-N voltage is available in the
FLOAT format.
Address = 01 is approved as the UMG 96RM-E device
address.
The Query Message appears as follows:
Description Hex Note
Device address 01 UMG 96RM, address= 1
Function 03 „Read Holding Reg.“
Start Addr. Hi 4A 19000dez = 4A38hex
Start Addr. Lo 38
Ind. Value Hi 00 2dez = 0002hex
Ind. Value Lo 02
Error Check -
