126

UMG 96RM-E

Table of Contents

Connection Example2
- Table of Contents2
Content4
General4
Inspection on Receipt6
- Available Accessories7
Product Description8
- Proper Use8
- Performance Characteristics - UMG 96RM-E10
- Measuring Process11
- Operating Concept11
- Gridvis Network Analysis Software11
- Connection Variants12
Mounting13
Installation15
- Power Supply15
- Measuring Voltage16
- Current Measurement Via I1 to I422
- Residual Current Measurement (RCM) Via I5, I631
- Temperature Measurement Input35
- RS485 Interface36
- Ethernet Interface39
- Digital In-/Outputs40
- LED Status Bar45
Operation46
- Display Mode46
- Programming Mode46
- Parameters and Measured Values48
- Button Functions49
Configuration50
- Connecting the Supply Voltage50
- Current and Voltage Transformers50
- Programming the Current Transformer for I1 to I352
- Programming the Voltage Transformer53
- Programming Parameters54
- TCP/IP Configuration55
- RS485 Device Address (Addr. 000)58
- RS485 Baud Rate (Addr. 001)58
- MODBUS Gateway (Addr. 002)59
- User Password (Addr. 050)59
Parameter60
- Mean Value60
- Averaging Method60
- Min. and Max. Values60
- Mains Frequency (Addr. 034)61
- Energy Meter62
- Reset Energy Meter (Addr. 507)62
- Harmonics63
- Measured Value Rotation64
- Measured Value Indocations64
- Phase Sequence66
- LCD Contrast (Addr. 035)66
- Backlight66
- Time Recording67
- Operating Hours Meter68
- Serial Number (Addr. 754)68
- Drag Indicator69
- Recordings70
Putting into Service71
- Connecting the Supply Voltage71
- Applying the Measuring-Circuit Voltage71
- Applying the Measuring-Circuit Current71
- Phase Sequence72
- Check Phase Assignment72
- Checking the Energy Measurement72
- Applying the Residual Current72
- Failure Monitoring (RCM) for I5, I673
- Checking the Measurement75
- Checking the Individual Outputs75
- Checking the Total Power Outputs75
RS485 Interface76
Digital Outputs78
- Impulse Output80
Service and Maintenance86
- Service86
- Device Calibration86
- Calibration Intervals86
- Firmware Update87
- Battery87
- Battery Monitoring Function88
- Replacing the Battery89
Error/Warning Messages90
Technical Data96
- Function Parameters104
- Table 1 – Parameter List106
- Table 2 - Modbus Address List110
- Number Formats113
- Dimension Diagrams114
Measured Value Displays Overview116
Connection Example 1122
- Connection Example 2123
Basic Functions Quick Guide124
TCP/IP Addressing Quick Guide125
