Comparators and monitoring threshold values
Five comparator groups (1-5) and 10 comparators per
group (A – J) can be selected in order to monitor/control
the thresholds. The results of the comparators A to J can
be linked with AND or OR operators
The result of the AND and OR operator can be allocated
to the respective digital output.
The function “display blinking” can be additionally
assigned to every comparator group. The effect is the
change of the display backlight between maximum and
minimum brightness when the comparator output is
active.
Fig.: Software GridVis, configuration menu
