The UMG 96RM-E can be used in industrial and domestic
settings.
Device characteristics
• Supply voltage:
Option 230V: 90V - 277V (50/60Hz) or
DC 90V - 250V; 300V CATIII
Option 24V: 24 - 90V AC / DC; 150V CATIII
• Frequency range: 45 - 65Hz
Device functions
• 3 voltage measurements, 300V
• 4 current measurements
(via current transformers ../5A or ../1A)
• 2 residual current measurements
(via residual current transformers ../30mA) or
optionally 2 temperature measurements
• RS485 interface, Ethernet
• 2 digital outputs and additional 3 digital
inputs/outputs
• Clock and memory function
