Temperature measurement input
2 optional inputs.
Update time 1 second
Connectable sensors PT100, PT1000, KTY83, KTY84
Total burden (sensor + cable) max. 4 kOhm
Cable length (digital inputs and outputs, temperature measurement input)
Up to 30m Unshielded
More than 30m Shielded
Sensor type Temperature range Resistor range Uncertainty in measurement
KTY83 -55°C ... +175°C 500Ohm ... 2,6kOhm ± 1,5% rng
KTY84 -40°C ... +300°C 350Ohm ... 2,6kOhm ± 1,5% rng
PT100 -99°C ... +500°C 60Ohm ... 180Ohm ± 1,5% rng
PT1000 -99°C ... +500°C 600Ohm ... 1,8kOhm ± 1,5% rng
