Table 89: Warning messages
Message Description
WARNING – UPS
– BATTERY NOT
CONNECTED
This is an auto reset warning. The minimum and maximum Battery
Voltage that occurs within each 10 second window is stored. At the
end of each 10 second window, if the difference between the min and
max battery voltage is greater than 0.5 V, a counter is increased. If the
difference between them is less than 0.5 V, the counter is reset to 0.
This warning is set when the Battery Disconnected Counter >= 4 (The
intent is for 4 consecutive 10 second windows to see battery voltage
fluctuations to set this fault)
It is released when the Battery Disconnected Counter is 0 for 60
continuous seconds.
WARNING – UPS
– CHECK BATTERY
CONNECTION
This manual reset warning is set when Battery Voltage > 16.0 V.
(Indicates only the UPS output is connected to the battery leads). It is
released when Battery Voltage < 16.0 V.
113
YMC
2
Mod B with OptiView
™
Control Center
