History details screen
Figure 34: History details screen
This screen allows the user to see an on-screen printout of all the system parameters at the time of
the selected shutdown. Not all screens are shown above. The number of screens required to display
all of the data varies according to type of motor starter and options applied.
Table 68: Display only fields
Field/LED name Description
History Printout This is the on-screen printout of the system parameters.
Table 69: Programmable
Button Description
Page Up / Page Down Scroll up in the displayed data (if applicable).
Print History
This generates a report listing the status of the chiller parameters at the
time of the selected shutdown.
Table 70: Navigation
Button Description
Home Causes an instant return to the Home Screen.
History Causes a return to the History Screen.
89
YMC
2
Mod B with OptiView
™
Control Center
