Operations screen
Figure 32: Operations screen
This screen allows definition of general parameters having to do with the operation of the chiller.
Table 62: Display only fields
Field/LED name Description
Chiller Run Time
Displays the amount of time the chiller has been running since the
last start signal was received. Value is reset to zero when the chiller
enters Coastdown. It remains at zero while shutdown and during “MBC
Startup”.
Number of Starts Displays the number of the starts the chiller has initiated.
Operating Hours Displays the total accumulated run time of the chiller.
Table 63: Programmable
Button Access Description
Control Source Operator
Define whether the control of the chiller will be Local, Digital
Remote, Analog Remote, Modem Remote or BAS (ISN)
Remote.
Table 64: Navigation
Button Description
Home Causes an instant return to the Home Screen.
Setup Return to the Setup Screen.
YMC
2
Mod B with OptiView
™
Control Center
86
