Table 14: Programmable
Button Access Description
Local Leaving Chilled
Liquid Temperature -
Setpoint
Operator
This value allows the user to define the Leaving Chilled
Liquid Temperature that is to be maintained by the chiller. It
is programmable over the range of 38.0°F to 70.0°F (water)
or 10.0°F to 70.0°F (brine). If Smart Freeze (see below) is
enabled, the range is 36.0°F to 70.0°F (water).
When the chiller is running, performing capacity control, any
change to the LCHLT setpoint results in a ramp from the old
value to the new value at the programmed LCHLT setpoint
ramp rate.
Local Leaving Chilled
Liquid Temperature -
Range
Operator
This is the range over which an analog or a digital signal
(PWM) can reset the Leaving Chilled Liquid Temperature
setpoint above the operator programmed Base Setpoint.
Leaving Chilled Liquid
Temperature Cycling
Offset - Shutdown
Operator
This value allows the user to specify the Leaving Chilled
Liquid Temperature at which the chiller will shut down
on a LEAVING CHILLED LIQUID – LOW TEMPERATURE
cycling shutdown. This is done by defining an offset below
the Leaving Chilled Liquid Temperature setpoint. It is
programmable over a range of 1°F to 64°F.
Leaving Chilled Liquid
Temperature Cycling
Offset - Restart
Operator
This value allows the user to specify the Leaving Chilled
Liquid Temperature at which the chiller will restart
after a shutdown on a LEAVING CHILLED LIQUID – LOW
TEMPERATURE cycling shutdown. This is done by defining
an offset above the Leaving Chilled Liquid Temperature
setpoint. It is programmable over a range of 0°F to 70°F.
Table 15: Navigation
Button Description
Home Causes an instant return to the Home Screen.
39
YMC
2
Mod B with OptiView
™
Control Center
