Table 16: Display only fields
Field/LED name Description
Condenser Liquid Flow
Switch
Indicates whether flow is present in the condenser.
Condenser Liquid
Pump (Run/Stop)
Displays the command presently sent by the control center to the
Condenser Liquid Pump run contacts.
Refrigerant Level Displays the present position of the refrigerant level.
Active Level Setpoint Displays the setpoint to which the refrigerant level is being controlled.
Level Control Valve
Command
Displays the position command to the level control valve in percent of
travel with 0% full closed to 100% full open.
Table 17: Navigation
Button Description
Home Causes an instant return to the Home Screen.
