Table 18: Display only fields
Field/LED name Description
Leaving Condenser
Liquid Temperature
Setpoints – Shutdown
Displays the Leaving Condenser Liquid Temperature at which the
Heat Pump will shut down on LEAVING CONDENSER LIQUID – HIGH
TEMPERATURE cycling shutdown in Heating mode. See Leaving
Condenser Liquid Temperature Cycling Offset – Shutdown Setpoint
description below.
Leaving Condenser
Liquid Temperature
Setpoints – Effective
Offset
Displays the actual offset being used to create the Leaving Condenser
Liquid Temperature setpoints – Shutdown temperature above. See
Leaving Condenser Liquid Temperature Cycling Offset – Shutdown
Setpoint description below.
Leaving Condenser
Liquid Temperature
Setpoints – Restart
Displays the Leaving Condenser Liquid Temperature at which the
Heat Pump will restart after shutting down on LEAVING CONDENSER
LIQUID – HIGH TEMPERATURE cycling shutdown in Heating mode. See
Leaving Condenser Liquid Temperature Cycling Off-set – Restart Setpoint
description below.
Leaving Condenser
Liquid Temperature
Setpoints – Offset
Displays the offset being used to create the Leaving Condenser Liquid
Temperature Setpoints
Restart temperature above. See Leaving Condenser Liquid Temperature
Cycling Offset – Restart Setpoint description below.
Note: For fields requiring access level of SERVICE, service
technicians refer to the OptiView Control Center - Service Instructions
(Form 160.84-M2) for operation instructions and explanation of all
programmable setpoints and display values.
43
YMC
2
Mod B with OptiView
™
Control Center
