Jomox ALPHA BASE User Manual

Version OS 1.0
7.4.3 FM Synth Envelope Page B
If you switch to page B in the FM Synth, the following screen is shown:
F
E
G
1
A
t
E
G
1
R
l
S
1
A
m
t
S
1
F
M
M
O
O
O
1
O
O
1
2
7
O
O
O
Every row page corresponds to one sine operator 1-4. As all 4 pages are the same, only
page 1 for sine operator 1 is listed here. The other pages yield the same for sine
operators 2-4.
7.4.3.1 EG1At = Sine Operator 1 Envelope Generator Attack <0-127>
This parameter controls the attack time of above described A/R envelope. Every
Operator has its own A/R envelope.
7.4.3.2 EG1Rl = Sine Operator 1 Envelope Generator Release <0-127>
This parameter controls the release time of the above described A/R envelope.
7.4.3.3 S1Amt = Sine Operator EG1 VCA Amount <0-127>
This parameter controls the amount of the A/R envelope generator 1 to the VCA. This
also controls the volume of the specific operator. The envelope masks the sine operator,
and with an amount of <000> the operator is turned off in the mix of the voice output.
7.4.3.4 S1FM = Sine Operator EG1 FM Amount <0-127>
This parameter controls the FM amount of the A/R envelope generator 1 to sine
operator 1. The envelope modulates the frequency of the sine operator. This is useful
for decaying tomtom-like sounds.
ALPHA BASE Operating Manual 61

Jomox ALPHA BASE Specifications

General

Voices	11
Analog Voices	8
Sequencer	Yes
Connectivity	MIDI In/Out/Thru, USB
Display	LCD
Type	Drum Machine
Effects	Delay, Reverb
Outputs	Main stereo output, headphones output
Inputs	2x 6.3mm Jack Inputs
Memory	Pattern
Power Supply	External Power Supply
Polyphony	11
Synthesis	Analog and Digital
