Chapter 3 INSTALLATION OF THE DISPLAY UNIT
3.7 CONNECTING TO OTHER MAKER'S GPS, COMPASS OR NMEA HEADING OUTPUT DEVICE
3-19
3
NSTALLATION MANUAL
ļ Baud Rate Setting
For details of operations, refer to "4.1 OPENING THE ADJUST MENU" "4.7.2
HEADING EQUIPMENT".
1 Hold down the [MENU] key.
"Code Input" screen appears.
2 Input "0" using the cursor keys, then press the [ENT] key.
"Adjust Menu" screen appears.
3 Press the cursor keys to select COM Port Setting , then press the [ENT]
key.
"COM Port Setting" screen appears.
4 Press the cursor keys to select Baud Rate , then press the [ENT] key.
"Baud Rate" screen appears.
5 Set the baud rate.
"1. Gyro/Compass" (J5)
"2. GPS" (J3)
"3. NMEA1" (J4)
"4. NMEA2ā (J6)
Auto 4800bps 38400bps can be selected.
Set the baud rate for GPS, GPS compass and NMEA heading output device.
Reference:
NMEA2 does not operate.
