JUKI IT-100D User Manual

83
*
*
*
1
1
1
2
2
2
2
2
2
2
2
1
1
2
51
52
53
55
56
58
59
60
64
70
71
72
73
76
-36 to 36
-36 to 36
-36 to 36
1/0
1/0
1/0
1/0
1/0
0 to 250
0/1
0 to 5
0 to 5
1/0
1/0
T-SON
0
T-SOFF
0
T-EOFF
0
FLAT
1
RATRM
0
HPOS
0
SBTO
1
SBTQ
0
S-WAIT
170
F-SDFL
0
F-ACRA
0
F-ACR
1
F-RET
1
F-SCS
0
88
88
88
89
89
89
89
89
89
90
90
90
90
Compensation
of solenoid-on
timing of
reverse feed
stitching at the
start of sewing
Compensation
of solenoid-off
timing of
reverse feed
stitching at the
start of sewing
Compensation
of solenoid-off
timing of
reverse feed
stitching at the
end of sewing
Foot lift after
thread
trimming
Reverse
revolution to lift
the needle
after thread
trimming
Function of
holding
predetermined
upper/lower
position of the
needle bar
Function of
Auto/Manual
change-over of
reverse feed
stitching at the
start of sewing
Function of
stop
immediately
after reverse
feed stitching
at the start of
sewing
Change-over
speed of
condensation
stitch or EBT
(end back tack)
Function of
soft-down of
presser foot
Function of
limitation of re-
acceleration
from reduction
of speed
Function of
limitation of
acceleration at the
start of rotation
Retry function
Function to
select the start-
up speed of the
sewing machine
Compensation of starting the solenoid for reverse feed stitching
when reverse feed stitching at the start of sewing is performed.
Compensation of releasing the solenoid for reverse feed stitching
when reverse feed stitching at the start of sewing is performed.
Compensation of releasing the solenoid for reverse feed stitching
when reverse feed stitching at the end of sewing is performed.
Function of lifting presser foot at the time of (after) thread
trimming
0 : Not provided with the function of lifting presser foot after
thread trimming
1 : Provided with the function of lifting presser foot
automatically after thread trimming
Function of reverse revolution to lift the needle at the time of
(after) thread trimming
0 : Not provided with the function of reverse revolution to lift
the needle after thread trimming
1 : Provided with the function of reverse revolution to lift the
needle after thread trimming
Function of holding predetermined upper/lower position of the
needle bar
0 : Not provided with the function of holding predetermined
upper/lower position of the needle bar
1 : Provided with the function of holding predetermined upper/
lower position of the needle bar
This function can specify the sewing speed of reverse feed
stitching at the start of sewing.
0 : The speed will depend on the manual operation by pedal,
etc.
1 : The speed will depend on the specified reverse feed
stitching speed (No. 8).
Function at the time of completion of reverse feed stitching at the
start of sewing
0 : Not provided with the function of temporary stop of the
sewing machine at the time of completion of reverse feed
stitching at the start of sewing
1 : Provided with the function of temporary stop of the sewing
machine at the time of completion of reverse feed stitching
at the start of sewing.
Initial speed when starting EBT
Presser foot is slowly lowered.
0 : Presser foot is rapidly lowered.
1 : Presser foot is slowly lowered.
Speed limitation is performed at the time of re-acceleration on the
way of reducing speed of the sewing machine.
It is effective when operating inching sewing.
Speed limitation is performed at the time of start-up of the sewing
machine (excluding the start of sewing).
It is effective when operating inching sewing.
This function is used when needle cannot pierce materials .
0 : Normal
1 : Retry function is provided.
Starting curve of the sewing machine is selected.
0 : Normal curve
1 : More sharp curve
* Do not change the set values with asterisk (*) mark as they are functions for maintenance. If the standard set value set at the time of
delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
If it is necessary to change the set value, please purchase the Engineer's Manual and follow the instructions. (Descriptions of setting in
this list are the standard values at the time of delivery of LZ-2290A.)
However, contents of function setting are subject to change for improvement of function and performance without notice.
