Trouble Cause (1) Cause (2) Check and corrective measures
6. Defective thread trim-
ming
6-1) Sharpness of the knife is defective. 1-A) Worn-out of the moving and counter knives. Replace the moving and counter knives.
1-B) Engagement of the moving and counter knives is
defective.
Properly adjust the height and position of the
moving and counter knives.
1-C) Parallel of the blade section of counter knife is de-
fective.
Properly adjust the parallel of the blade section
of counter knife.
1-D) Attaching position of the counter knife is defective. Properly adjust the attaching position of counter
knife.
6-2) Double cutting for the needle thread.
(Thread waste remains inside the
cylinder arm cap.)
2-A) There is a burr on thread spread-
ing section
A
of the moving knife.
The shape of the thread trimmed
becomes and thread
waste remains.
Paying attention to the blade section, polish with
polishing power, or replace the moving knife.
2-B) Shuttle upper spring has scratches. (The shape of
the thread trimmed becomes and thread
waste remains.)
Remove the scratches.
6-3)
Moving knife does not spread threads.
3-A) Initial position of the moving knife is maladjusted. Adjust the initial position of the moving knife.
3-B) Thread trimmer cam position is inadequate. Adjust the thread trimmer cam position.
3-C) Position of the shuttle upper spring is defective. Adjust the position of shuttle upper spring.
6-4) Stitch skipping at the nal stitch 4-A) Timing of the needle to the inner hook and the
clearance between them are defective.
Adjust the timing and the clearance.
4-B) Work clamp foot is large. Let the beginning of stitch come closer to the
work clamp foot by moving the pattern.
4-C) Loop of the needle thread falls down. Attach the needle with the long groove orienting
slightly to the right (approximately 20°)
6-5) Bobbin thread cannot be cut. 5-A) Bobbin thread tension is low. Strong then the bobbin thread tension.
5-B) Needle hole size of the needle hole guide is large. Replace the needle hole guide with a new one
having a smaller hole diameter.
