JUKI LK-1900B series Engineer's Manual

– 91 –
7. Miscellaneous
(1) Various printed wiring boards
1) FLT-T board (asm.)
 Thisboardisthepowersupplylterboardfor3-phasespecication.
2) FLT-CE board (asm.)
 ThisboardisthepowersupplylterboardforEurope.
 Performthenoisereduction.
No. Connectorandfusename Connectiondestination,name Remarks
❶
CN1 Powerswitch Powerinlet
❷
CN16 SDC board Power outlet
❸
F1,F2,F3 20Atime-lagfuse Non-removable
No. Connectorandfusename Connectiondestination,name Remarks
❶
CN1 Powerswitch Powerinlet
❷
CN16 SDC board Power outlet
❸
F1,F2 20Atime-lagfuse Non-removable
❶
❷
❸
❶
❷
❸
