JUKI LK-1900B series Engineer's Manual

– 158 –
14. Table drawings
(1) Table type for longitudinal Installation
ForLK-1900B,1900BB
ForLK-1901B
ForLK-1903B,1903BB
PartNo.:40143093
❶
4×2drilledhole,depth10ontherearside[Standinstallinghole]
❷
Drawer stopper installing position (One place on the rear side)
❸
6×3drilledhole,depth10ontherearside[Drawerinstallinghole]
❹
4×8 drilled hole
❺
30drilledhole,51spotfacedepth16
ZZ
42
500
570
199
1130
1200
411 50 50
133.5
418.5
110
283
270
40
Z-Z(1:2)
Ø 36
Ø 16
135
120
6
35
263.5
120
390
488
503
85
40
256
1046
85
25
30.5
R30
R30
R10
R10
50
38
Ø
25
10
50
85.7
56
±1
148
±0.5
630
±3
419 116
±4
257
±1
306
±1
139.5
±0.5
48.7
±1
259.8
±1
158
±0.5
360
±1
28
±0.5
120
10
320
±1
158.8
±1
115
±1
810
±1
38
±0.5
124
±1
175.6
±1
17.5

4×R10
❶
❷
❺
❹
❻
❼
❾
󱢳
󱢴
󱢵
󱢶
󱢷
󱢶
❽
❸
󱢸
❻
For oil drain funnel installing
❼
3×7drilledhole,depth6
❽
8 drilled hole
❾
4×9drilledhole,26spotfacedepth1
󱢳
3×3drilledhole,depth10ontherearside[Powerswitchinstallinghole]
󱢴
17drilledhole
󱢵
28 drilled hole
󱢶
R2 (all corners)
󱢷
Face side
󱢸
3×3drilledhole,depth10ontherearside[Pedalinstallinghole]
