– 40 –
(27) Installing the feed plate support plate
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of the
sewing machine.
Standard adjustment
(28) Installation of the feeder bar rear cover
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of the
sewing machine.
Standard adjustment
The clearance between the feeder bar rear cover
❶
and the upper surface of the work feed presser plate
❹
is about 1mm.
When the feeder bar
❺
is moved in the direction of the arrow
A
, there must be a clearance at the notch
part of the sewing machine frame
❸
.
Machine
bed
Clearance
