Table 23: Uplink Modules Connector Pinout Information for EX3200 and EX4200
Switches (continued)
Pin NamePin Number
POWER (12V)D19
GNDD20
GNDE1
XAUI0_TX0NE2
XAUI0_TX1PE3
XAUI0_TX2NE4
XAUI0_TX3PE5
XAUI1_TX0NE6
XAUI1_TX1PE7
XAUI1_TX2NE8
XAUI1_TX3PE9
STX28NE10
STX27PE11
STX26NE12
STX25PE13
SGMIITXNE14
Uplink_Hotswap_LEDE15
Uplink_Spare_IntrE16
Uplink_Status_LED1E17
Uplink_P27_LED0E18
POWER (12V)E19
POWER (12V)E20
GNDF1
77Copyright © 2010, Juniper Networks, Inc.
Chapter 3: Component Specifications
