Connecting a Virtual Chassis Cable to an EX4200 Switch
EX4200 switches have two Virtual Chassis ports on the rear panel. You can use the Virtual
Chassis ports to interconnect up to 10 EX4200 switches, enabling them to operate as a
unified single high bandwidth switch. To see illustrations of a few Virtual Chassis cabling
configuration examples, see “Virtual Chassis Cabling Configuration Examples for EX4200
Switches” on page 107.
Ensure that you have the following parts and tools available:
•
A cross-head screwdriver (provided in the uplink module kit)
NOTE: If you order Virtual Chassis cables separately, you must reuse the locking covers
provided with the original cable or order Virtual Chassis cable locking covers also
separately.
To connect a Virtual Chassis cable to an EX4200 switch (see Figure 51 on page 140):
1. Taking care not to touch module components, pins, leads, or solder connections,
remove the Virtual Chassis cable from its bag.
2. Using both hands, place the Virtual Chassis cable connector in the empty Virtual
Chassis port and slide it in gently until it is fully seated.
3. Slide the locking cover over the Virtual Chassis cable connector.
4. Tighten the screws on the locking cover by using the cross-head screwdriver.
139Copyright © 2010, Juniper Networks, Inc.
Chapter 10: Installing Switch Components

Juniper EX3200 Series Specifications

General

Model	EX3200 Series
Rack Units	1 U
Layer	Layer 2/3
Maximum VLANs	4094
Ports	24 or 48
Power Supply	AC or DC power supply options
Power Supply Voltage	100 to 240 VAC or -48 VDC
Operating Humidity	10% to 90% non-condensing
Uplink Ports	4 SFP or SFP+
Operating Temperature	32°F to 104°F (0°C to 40°C)
