Table 24: Virtual Chassis Ports (VCPs) Connector Pinout Information (continued)
Pin NamePin Number
P1TXP1A5
P1TXN1A6
GNDA7
P1TXP2A8
P1TXN2A9
GNDA10
P1TXP3A11
P1TXN3A12
GNDA13
NCA14
NCA15
GNDA16
NCA17
NCA18
NCA19
NCA20
NCA21
GNDA22
P2TXP0A23
P2TXN0A24
GNDA25
P2TXP1A26
P2TXN1A27
GNDA28
Copyright © 2010, Juniper Networks, Inc.82
Complete Hardware Guide for EX3200 and EX4200 Ethernet Switches
