Table 4: LCD Panel Menu Options in EX3200 and EX4200 Switches (continued)
DescriptionMenu
The Status menu has the following options:
•
Show VCP status—Choose one of the following:
•
Press the Enter button to display the Virtual Chassis port (VCP) status: Up, Down, Disabled. This menu
option is available only for an EX4200 switch that is a member of a Virtual Chassis configuration.
•
Press the Menu button to go to the next option in the Status menu.
•
Show PSU status—Choose one of the following:
•
Press the Enter button to display the status of the power supply: OK, Failed, Absent.
•
Press the Menu button to go to the next option in the Status menu.
•
Show Environment status—Choose one of the following:
•
Press the Enter button to display the status of the fan and temperature:
•
Fan status: OK, Failed, Absent
•
Temp status: OK, High, Shutdown
•
Press the Menu button to go to the next option in the Status menu.
•
Show Junos version—Choose one of the following:
•
Press the Enter button to version of Junos OS for EX Series switches loaded on the switch.
•
Press the Menu button to go to the next option in the Status menu.
•
EXIT STAT MENU?—Choose one of the following:
•
Press the Enter button to exit the Status menu. Then press the Menu button to go to the Maintenance
menu.
•
Press the Menu button to return to the Show VCP status option.
If you do not want users to use Status menu options, disable the entire menu or individual menu options. See
Configuring the LCD Panel on EX Series Switches (CLI Procedure).
STATUS
Copyright © 2010, Juniper Networks, Inc.16
Complete Hardware Guide for EX3200 and EX4200 Ethernet Switches

Juniper EX3200 Series Specifications

General

Model	EX3200 Series
Rack Units	1 U
Layer	Layer 2/3
Maximum VLANs	4094
Ports	24 or 48
Power Supply	AC or DC power supply options
Power Supply Voltage	100 to 240 VAC or -48 VDC
Operating Humidity	10% to 90% non-condensing
Uplink Ports	4 SFP or SFP+
Operating Temperature	32°F to 104°F (0°C to 40°C)
