MAC-in-MAC Packet Hashing
Packets using the MAC-in-MAC EtherType are hashed by the hashing algorithm using
the Layer 2 payload source MAC, Layer 2 payload destination MAC, and Layer 2 payload
EtherType fields. See Table 8 on page 15.
Hashing using the fields in the MAC-in-MAC EtherType packet is first supported on
EX4300 switches in Release 13.2X51-D20. Hashing using the fields in the MAC-in-MAC
EtherType is not supported on earlier releases.
The fields used by the hashing algorithm for MAC-in-MAC hashing are not
user-configurable.
•
✓—Field is used by the hashing algorithm, by default.
•
Χ—Field is not used by the hashing algorithm, by default.
Table 8: MAC-in-MAC Hashing Fields
QFX5100EX4300Field
✓✓Layer 2 Payload Source MAC
✓✓Layer 2 Payload Destination MAC
✓✓Layer 2 Payload EtherType
ΧΧLayer 2 Payload Outer VLAN
Layer 2 Header Hashing
Layer 2 header fields are used by the hashing algorithm when a packet’s EtherType is
not recognized as IP (IPv4 or IPv6), MPLS, or MAC-in-MAC. The Layer 2 header fields are
also used for hashing IPv4, IPv6, and MPLS traffic instead of the payload fields when the
hash mode is set to Layer 2 header.
•
✓—Field is used by the hashing algorithm, by default.
•
Χ—Field is not used by the hashing algorithm, by default.
•
(configurable)—Field can be configured to be used or not used by the hashing algorithm.
Table 9: Layer 2 Header Hashing Fields
QFX5100EX4300Field
✓
(configurable)
✓
(configurable)
Source MAC
✓
(configurable)
✓
(configurable)
Destination MAC
15Copyright © 2015, Juniper Networks, Inc.
Chapter 1: Interfaces Overview

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
