Juniper EX3300 Hardware Guide

Table 29: VLAN Options
Your ActionFunctionField
If you select Trunk, you can:
1. Click Add to add a VLAN member.
2. Select the VLAN and click OK.
3. (Optional) Associate a native VLAN
ID with the port.
If you select Access, you can:
1. Select the VLAN member to be
associated with the port.
2. (Optional) Associate a VoIP VLAN
with the interface. Only a VLAN with
a VLAN ID can be associated as a
VoIP VLAN.
Click OK.
Specifies the mode of operation for the
port: trunk or access.
Port Mode
Table 30: IP Options
Your ActionFunctionField
1. Select the check box IPv4 address.
2. Type an IP address—for example,
10.10.10.10.
3. Enter the subnet mask or address
prefix. For example, 24 bits
represents 255.255.255.0.
4. Click OK.
Specifies an IPv4 address for the selected
LAG.
IPv4 Address
1. Select the check box IPv6 address.
2. Type an IP address—for example,
2001:ab8:85a3::8a2e:370:7334.
3. Enter the subnet mask or address
prefix.
4. Click OK.
Specifies an IPv6 address for the selected
LAG.
IPv6 Address
Related
Documentation
Configuring Aggregated Ethernet Links (CLI Procedure) on page 82•
• Example: Configuring Aggregated Ethernet High-Speed Uplinks Between an EX4200
Virtual Chassis Access Switch and an EX4200 Virtual Chassis Distribution Switch
• Example: Configuring Aggregated Ethernet High-Speed Uplinks with LACP Between an
EX4200 Virtual Chassis Access Switch and an EX4200 Virtual Chassis Distribution Switch
• Verifying the Status of a LAG Interface on page 234
• Configuring Aggregated Ethernet LACP (CLI Procedure) on page 86
85Copyright © 2015, Juniper Networks, Inc.
Chapter 2: Configuration Tasks

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
