Solution Traffic statistics fields for logical interfaces in show interfaces commands show only

control traffic; the traffic statistics do not include data traffic. You can view the statistics

for all traffic only per physical interface.

IPv6 Interface Traffic Statistics Are Not Supported

Problem Description: The IPv6 transit statistics in the show interfaces command display all 0

values.

Solution EX Series switches do not support the collection and reporting of IPv6 transit statistics.

SNMP Counters ifHCInBroadcastPkts and ifInBroadcastPkts Are Always 0

Problem Description: The values for the SNMP counters ifHCInBroadcastPkts and

ifInBroadcastPkts are always 0.

Solution The SNMP counters ifHCInBroadcastPkts and ifInBroadcastPkts are not supported for

aggregated Ethernet interfaces on EX Series switches.

Documentation

Verifying the Status of a LAG Interface on page 234•

• Example: Configuring Aggregated Ethernet High-Speed Uplinks Between an EX4200

Virtual Chassis Access Switch and an EX4200 Virtual Chassis Distribution Switch

• Example: Configuring Aggregated Ethernet High-Speed Uplinks with LACP Between an

EX4200 Virtual Chassis Access Switch and an EX4200 Virtual Chassis Distribution Switch

Troubleshooting Interface Configuration and Cable Faults

Troubleshooting interface configuration and connectivity on the EX Series switch:

Interface Configuration or Connectivity Is Not Working on page 330

Interface Configuration or Connectivity Is Not Working

Problem Description: You encounter errors when you attempt to configure an interface on the

switch, or the interface is exhibiting connectivity problems.

Solution Use the port troubleshooter feature in the J-Web interface to identify and rectify port

configuration and connectivity related problems.

To use the J-Web interface port troubleshooter:

1. Select the option Troubleshoot from the main menu.

2. Click Troubleshoot Port. The Port Troubleshooting wizard is displayed. Click Next.

3. Select the ports to troubleshoot.

4. Select the test cases to be executed on the selected port. Click Next.

Network Interfaces for EX4300 Switches

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6
