Juniper EX3300 Hardware Guide

Table 28: Aggregated Ethernet Interface Options
Your ActionFunctionField
None. The name is supplied by the
software.
Specifies the name of the aggregated
interface.
Aggregated Interface
Select from the list.Specifies the mode in which LACP
packets are exchanged between the
interfaces. The modes are:
•
None—Indicates that no mode is
applicable.
•
Active—Indicates that the interface
initiates transmission of LACP packets
•
Passive—Indicates that the interface
responds only to LACP packets.
LACP Mode
Enter a description.Specifies a description for the LAG.Description
To add interfaces to the LAG, select the
interfaces and click Add. For an EX8200
Virtual Chassis configuration, select the
member, FPC, and the interface from the
list. Click OK.
To remove an interface from the LAG,
select the interface and click Remove.
NOTE: Only interfaces that are
configured with the same speed can be
selected together for a LAG.
Specifies the interfaces in the LAG.Interface
Select the check box to enable log
generation, or clear the check box to
disable log generation.
Specifies whether to enable generation
of log entries for the LAG.
Enable Log
Copyright © 2015, Juniper Networks, Inc.84
Network Interfaces for EX4300 Switches

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
