Juniper EX3300 Hardware Guide

lacp (Aggregated Ethernet)
Syntax lacp {
(active | passive);
admin-key key;
accept-data;
fast-failover;
link-protection {
disable;
(revertive |non-revertive);
}
periodic interval;
system-id mac-address;
system-priority priority;
}
Hierarchy Level [edit interfaces aex aggregated-ether-options]
Release Information Statement introduced before Junos OS Release 7.4.
Statement introduced in Junos OS Release 9.0 for EX Series switches.
fast-failover option introduced in Junos OS Release 12.2.
Description Configure the Link Aggregation Control Protocol (LACP) for aggregated Ethernet interfaces
only.
When you configure the accept-data statement at the [edit interfaces aeX
aggregated-ether-options lacp] hierarchy level, the router processes packets received on
a member link irrespective of the LACP state if the aggregated Ethernet bundle is up.
NOTE: When you configure the accept-data statement at the [edit interfaces
aeX aggregated-ether-options lacp] hierarchy level, this behavior occurs:
• By default, the accept-data statement is not configured when LACP is
enabled.
• You can configure the accept-data statement to improve convergence and
reduce the number of dropped packets when member links in the bundle
are enabled or disabled.
• When LACP is down and a member link receives packets, the router or
switch does not process packets as defined in the IEEE 802.1ax standard.
According to this standard, the packets should be dropped, but they are
processed instead because the accept-data statement is configured.
Default If you do not specify LACP as either active or passive, LACP remains passive.
Options active—Initiate transmission of LACP packets.
admin-key number—Specify an administrative key for the router or switch.
195Copyright © 2015, Juniper Networks, Inc.
Chapter 3: Configuration Statements

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
