Juniper EX3300 Hardware Guide

Related
Documentation
EX2200 Switches Hardware Overview•
• EX3200 Switches Hardware Overview
• EX3300 Switches Hardware Overview
• EX4200 Switches Hardware Overview
• EX4300 Switches Hardware Overview
• EX4500 Switches Hardware Overview
• EX6210 Switch Hardware Overview
• EX8208 Switch Hardware Overview
• EX8216 Switch Hardware Overview
• XRE200 External Routing Engine Hardware Overview
• Understanding PoE on EX Series Switches
• Understanding Aggregated Ethernet Interfaces and LACP on page 8
• Understanding Layer 3 Subinterfaces on page 18
Understanding Interface Naming Conventions on EX Series Switches
Juniper Networks EX Series Ethernet Switches use a naming convention for defining the
interfaces that is similar to that of other platforms running under Juniper Networks Junos
operating system (Junos OS). This topic provides brief information about the naming
conventions used for interfaces on EX Series switches. For additional information, see
the Junos OS Network Interfaces Configuration Guide.
This topic describes:
•
Physical Part of an Interface Name on page 6
•
Logical Part of an Interface Name on page 8
•
Wildcard Characters in Interface Names on page 8
Physical Part of an Interface Name
Network interfaces in Junos OS are specified as follows:
type-fpc / pic / port
EX Series switches apply this convention as follows:
•
type—EX Series interfaces use the following media types:
•
ge—Gigabit Ethernet interface
•
xe—10 Gigabit Ethernet interface
Copyright © 2015, Juniper Networks, Inc.6
Network Interfaces for EX4300 Switches

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
