switch-options redundant-trunk-group group-name interface
•
switch-options voip interface
Related
Documentation
Interface Ranges on page 66•
• EX Series Switches Interfaces Overview on page 3
• Configuring Gigabit Ethernet Interfaces (CLI Procedure) on page 32
• Configuring Aggregated Ethernet Links (CLI Procedure) on page 82
• Configuring a Layer 3 Subinterface (CLI Procedure) on page 97
• interface-range on page 193
802.1Q VLANs Overview
For Ethernet, Fast Ethernet, Tri-Rate Ethernet copper, Gigabit Ethernet, 10-Gigabit
Ethernet, and aggregated Ethernet interfaces supporting VPLS, the Junos OS supports
a subset of the IEEE 802.1Q standard for channelizing an Ethernet interface into multiple
logical interfaces, allowing many hosts to be connected to the same Gigabit Ethernet
switch, but preventing them from being in the same routing or bridging domain.
Related
Documentation
• Configuring Dynamic 802.1Q VLANs
• 802.1Q VLAN IDs and Ethernet Interface Types
• Enabling VLAN Tagging
• Binding VLAN IDs to Logical Interfaces
• Configuring VLAN Encapsulation
• Configuring Extended VLAN Encapsulation
• Guidelines for Configuring VLAN ID List-Bundled Logical Interfaces That Connect CCCs
• Configuring a Layer 2 VPN Routing Instance on a VLAN-Bundled Logical Interface
• Configuring a VLAN-Bundled Logical Interface to Support a Layer 2 VPN Routing Instance
• Specifying the Interface Over Which VPN Traffic Travels to the CE Router
• Specifying the Interface to Handle Traffic for a CCC
• Configuring a Layer 2 Circuit on a VLAN-Bundled Logical Interface
• Configuring a VLAN-Bundled Logical Interface to Support a Layer 2 VPN Routing Instance
• Specifying the Interface to Handle Traffic for a CCC Connected to the Layer 2 Circuit
• Example: Configuring a Layer 2 VPN Routing Instance on a VLAN-Bundled Logical Interface
• Example: Configuring a Layer 2 Circuit on a VLAN-Bundled Logical Interface
• Configuring a Logical Interface for Access Mode
• Configuring a Logical Interface for Trunk Mode
• Configuring the VLAN ID List for a Trunk Interface
Copyright © 2015, Juniper Networks, Inc.26
Network Interfaces for EX4300 Switches

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
