show interfaces diagnostics optics
Syntax show interfaces diagnostics optics interface-name
Release Information Command introduced in Junos OS Release 10.0 for EX Series switches.
Command introduced in Junos OS Release 13.2X50-D15 for the QFX Series.
Description Display diagnostics data and alarms for Gigabit Ethernet optical transceivers (SFP, SFP+,
XFP, QSFP+, or CFP) installed in EX Series or QFX Series switches. The information
provided by this command is known as digital optical monitoring (DOM) information. For
a list of transceivers supported on EX Series switches and their specifications, including
DOM support, see Pluggable Transceivers Supported on EX Series Switches.
Thresholds that trigger a high alarm, low alarm, high warning, or low warning are set by
the transponder vendors. Generally, a high alarm or low alarm indicates that the optics
module is not operating properly. This information can be used to diagnose why a
transceiver is not working.
Options interface-name—Name of the interface associated with the port in which the transceiver
is installed: ge-fpc/pic/port, xe-fpc/pic/port, or et-fpc/pic/port.
Required Privilege
Level
view
Related
Documentation
Monitoring Interface Status and Traffic on page 233•
• Monitoring Interface Status and Traffic
• Installing a Transceiver in an EX Series Switch
• Installing a Transceiver in a QFX Series Device
• Removing a Transceiver from an EX Series Switch
• Removing a Transceiver from a QFX Series Device
• Junos OS Ethernet Interfaces Configuration Guide
List of Sample Output show interfaces diagnostics optics ge-0/1/0 (SFP Transceiver) on page 269
show interfaces diagnostics optics xe-0/1/0 (SFP+ Transceiver) on page 270
show interfaces diagnostics optics xe-0/1/0 (XFP Transceiver) on page 271
show interfaces diagnostics optics et-3/0/0 (QSFP+ Transceiver) on page 272
show interfaces diagnostics optics et-4/1/0 (CFP Transceiver) on page 273
Output Fields Table 47 on page 262 lists the output fields for the show interfaces diagnostics optics
command. Output fields are listed in the approximate order in which they appear.
Table 47: show interfaces diagnostics optics Output Fields
Field DescriptionField Name
Displays the name of the physical interface.Physical interface
Copyright © 2015, Juniper Networks, Inc.262
Network Interfaces for EX4300 Switches

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
