Juniper EX3300 Hardware Guide

Table 47: show interfaces diagnostics optics Output Fields (continued)
Field DescriptionField Name
Displays the magnitude of the laser bias power setting current,
in milliamperes. The laser bias provides direct modulation of
laser diodes and modulates currents.
Laser bias current
Displays the laser output power, in milliwatts (mW) and
decibels referred to 1.0 mW (dBm).
Laser output power
(Not available for QSFP+ transceivers)
Displays the laser temperature, in Celsius and Fahrenheit.Laser temperature
(Not available for SFP, SFP+, XFP, and QSFP+ transceivers)
Displays the temperature, in Celsius and Fahrenheit.Module temperature
Displays the voltage, in Volts.Module voltage
(Not available for XFP transceivers)
Displays the laser received optical power, in milliwatts (mW)
and decibels referred to 1.0 mW (dBm).
Laser rx power
(Not available for SFP, SFP+, QSFP+, and CFP transceivers)
Displays the receiver signal average optical power, in milliwatts
(mW) and decibels referred to 1.0 mW (dBm).
Receiver signal average optical power
(Not available for XFP, QSFP+, and CFP transceivers)
Displays whether the laser bias power setting high alarm is On
or Off.
Laser bias current high alarm
Displays whether the laser bias power setting low alarm is On
or Off.
Laser bias current low alarm
Displays whether the laser bias power setting high warning is
On or Off.
Laser bias current high warning
Displays whether the laser bias power setting low warning is
On or Off.
Laser bias current low warning
Displays whether the laser output power high alarm is On or
Off.
Laser output power high alarm
(Not available for QSFP+ transceivers)
Displays whether the laser output power low alarm is On or Off.Laser output power low alarm
(Not available for QSFP+ transceivers)
Displays whether the laser output power high warning is On or
Off.
Laser output power high warning
(Not available for QSFP+ transceivers)
263Copyright © 2015, Juniper Networks, Inc.
Chapter 5: Operational Commands

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
