Juniper EX3300 Hardware Guide

NOTE: The Power Used field is displayed in the output only for EX6210
switches.
On an EX4300 switch, if you compare the values in the Non-PoE power being consumed
field before and after enabling EEE, you will notice that power is saved when EEE is
enabled.
Related
Documentation
Configuring Energy Efficient Ethernet on Interfaces (CLI Procedure) on page 93•
• Understanding How Energy Efficient Ethernet Reduces Power Consumption on
Interfaces on page 16
Verifying That LACP Is Configured Correctly and Bundle Members Are Exchanging
LACP Protocol Packets
Verify that LACP has been set up correctly and that the bundle members are transmitting
LACP protocol packets.
1.
Verifying the LACP Setup on page 237
2.
Verifying That LACP Packets Are Being Exchanged on page 237
Verifying the LACP Setup
Purpose Verify that the LACP has been set up correctly.
Action To verify that LACP has been enabled as active on one end:
user@switch> show lacp interfaces xe-0/1/0
Aggregated interface: ae0
LACP state: Role Exp Def Dist Col Syn Aggr Timeout Activity
xe-0/1/0 Actor No Yes No No No Yes Fast Active
xe-0/1/0 Partner No Yes No No No Yes Fast Passive
LACP protocol: Receive State Transmit State Mux State
xe-0/1/0 Defaulted Fast periodic Detached
Meaning This ouput shows that LACP has been configured with one side as active and the other
as passive. When LACP is enabled, at least one side must be set as active for the bundled
link to be up.
Verifying That LACP Packets Are Being Exchanged
Purpose Verify that LACP packets are being exchanged between interfaces.
237Copyright © 2015, Juniper Networks, Inc.
Chapter 4: Routine Monitoring

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
