Before you configure LACP link protection, be sure you have:
•
Configured the aggregated Ethernet bundles—also known as link aggregation groups
(LAGs). See “Configuring Aggregated Ethernet Links (CLI Procedure)” on page 82.
•
Configured LACP for the interface. See “Configuring Aggregated Ethernet LACP (CLI
Procedure)” on page 86.
You can configure LACP link protection for all aggregated Ethernet interfaces on the
switch by enabling it at the global level on the switch or configure it for a specific
aggregated Ethernet interface by enabling it on that interface.
•
Configuring LACP Link Protection at the Global Level on page 88
•
Configuring LACP Link Protection at the Aggregated Interface Level on page 88
Configuring LACP Link Protection at the Global Level
To configure LACP link protection for aggregated Ethernet interfaces at the global level:
1. Enable LACP link protection on the switch:
[edit chassis aggregated-devices ethernet lacp]
user@switch# set link-protection
2. (Optional) Configure the LACP link protection for the aggregated Ethernet interfaces
to be in nonrevertive mode:
NOTE: LACP link protection is in revertive mode by default.
[edit chassis aggregated-devices ethernet lacp link-protection]
user@switch# set non-revertive
3. (Optional)To configure LACP system priority for the aggregated Ethernet interfaces:
[edit chassis aggregated-devices ethernet lacp]
user@switch# set system-priority
Configuring LACP Link Protection at the Aggregated Interface Level
To enable LACP link protection for a specific aggregated Ethernet interface:
1. Enable LACP link protection for the interface:
[edit interfaces aeX aggregated-ether-options lacp]
user@switch# set link-protection
2. (Optional) Configure the LACP link protection for the aggregated Ethernet interface
to be in revertive or nonrevertive mode:
•
To specify revertive mode:
[edit interfaces aeX aggregated-ether-options lacp link-protection]
user@switch# set revertive
•
To specify nonrevertive mode:
[edit interfaces aeX aggregated-ether-options lacp link-protection]
user@switch# set non-revertive
3. (Optional)To configure LACP system priority for an aggregated Ethernet interface:
Copyright © 2015, Juniper Networks, Inc.88
Network Interfaces for EX4300 Switches

Juniper EX3300 Specifications

General

Ethernet LAN	Yes
Authentication method	RADIUS, TACACS+
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Number of VLANs	4096
Networking standards	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Console port	-
ExpressCard slot	No
Fiber ports quantity	4
USB 2.0 ports quantity	0
Basic switching RJ-45 Ethernet ports quantity	48
Throughput	130 Mpps
Number of queues	8
MAC address table	16000 entries
Maximum data transfer rate	176 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Switch type	Managed
Switch layer	L2
Security algorithms	SSH-2
Power source	AC
AC input voltage	100 - 240 V
Power consumption (typical)	100 W
Form factor	1U
Product color	Black
Flash memory	1024 MB
Processor frequency	1000 MHz
Compatible operating systems	Junos
Operating altitude	0 - 3049 m
Non-operating altitude	0 - 4877 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Supported network protocols	IPv6

Weight and Dimensions

Depth	310 mm
Width	437 mm
Height	44 mm
Weight	4900 g
