Table 33: Line Cards Available for EX9208 Switches (continued)
Additional InformationDescriptionModel
“EX9200-4QS Line Card” on page 32A line card with four 40-Gigabit Ethernet
quad small form-factor pluggable plus
(QSFP+) ports
EX9200-4QS
“EX9200-6QS Line Card” on page 34A line card with six 40-Gigabit Ethernet
quad small form-factor pluggable plus
(QSFP+) ports and 24 10-Gigabit
Ethernet small form-factor pluggable
plus (SFP+) ports
EX9200-6QS
“EX9200-MPC Line Card” on page 3A modular line card that accepts any of
the following MICs:
•
EX9200-10XS-MIC
•
EX9200-20F-M-MIC
•
EX9200-40T-MIC
EX9200-MPC
“EX9200-32XS Line Card” on page 27A line card with 32 10-Gigabit Ethernet
small form-factor pluggable plus (SFP+)
ports
EX9200-32XS
“EX9200-40T Line Card” on page 31A line card with 40 10/100/1000BASE-T
ports that support RJ-45 connectors
EX9200-40T
“EX9200-40F Line Card” on page 28A line card with 40 1-Gigabit Ethernet
small form-factor pluggable (SFP) ports
EX9200-40F
“EX9200-40F-M Line Card” on page 30A line card with 40 1-Gigabit Ethernet
small form-factor pluggable (SFP) ports
with Media Access Control Security
(MACsec) capability
EX9200-40F-M
Cooling System
The cooling system in an EX9208 switch is a field-replaceable unit (FRU). It consists of
a hot-removable and hot-insertable fan tray. The fan tray contains six fans. The fan tray
installs vertically on the right back of the chassis and provides side-to-side chassis cooling.
See Cooling System and Airflow in an EX9208 Switch.
Power Supplies
Power supplies for the EX9208 switch are fully redundant, load-sharing, and
hot-removable and hot-insertable FRUs. Each EX9208 switch chassis can hold up to
four AC or DC power supplies.
Table 34 on page 85 shows the details of the power supplies available for EX9208
switches.
Copyright © 2016, Juniper Networks, Inc.84
