EX9204 Switch Hardware and CLI Terminology Mapping
This topic describes the hardware terms used in EX9204 switch documentation and the
corresponding terms used in the Junos OS CLI. See Table 32 on page 77.
Table 32: CLI Equivalents of Terms Used in Documentation for EX9204 Switches
Additional InformationItem in DocumentationValue (CLI)Description (CLI)
Hardware
Item (CLI)
“Chassis Physical
Specifications of an
EX9204 Switch” on
page 73
Switch chassis–EX9204Chassis
Midplane in an EX9200
Switch
Switch midplane–EX9204-BPMidplane
“Craft Interface in an
EX9200 Switch” on
page 20
Craft interface–Front Panel DisplayFPM Board
•
AC Power Supply in an
EX9204 Switch
•
DC Power Supply in an
EX9204 Switch
AC or DC power supplyn is a value in the range of
0–3. The value corresponds
to the power supply slot
number.
One of the following:
•
PS 1.4–2.52 kW;
90-264 V AC in
•
DC 2.4 kW Power
Entry Module
PEM(n)
Routing Engine Module in
an EX9200 Switch
RE modulen is a value in the range 0–1.
In base configuration, only
one entry appears.
In redundant configuration,
two entries appear; one for
each Routing Engine
module (RE module)
installed in the chassis.
RE–S–EX9200-1800X4Routing
Engine (n)
Switch Fabric Module in an
EX9200 Switch
SF modulen is a value in the range of
0–1.
Multiple line items appear
in the CLI if more than one
Switch Fabric modules (SF
modules) are installed in
the chassis.
CB0 and CB1 stand for SF
modules.
EX9200–SCBECB (n)
