Table 29: Line Cards Available for EX9204 Switches
Additional InformationDescriptionModel
“EX9200-2C-8XS Line Card” on page 25A line card with two 100-Gigabit
Ethernet C form-factor pluggable (CFP)
ports and eight 10-Gigabit Ethernet
small form-factor pluggable plus (SFP+)
ports
EX9200-2C-8XS
“EX9200-4QS Line Card” on page 32A line card with four 40-Gigabit Ethernet
quad small form-factor pluggable plus
(QSFP+) ports
EX9200-4QS
“EX9200-6QS Line Card” on page 34A line card with six 40-Gigabit Ethernet
quad small form-factor pluggable plus
(QSFP+) ports and 24 10-Gigabit
Ethernet small form-factor pluggable
plus (SFP+) ports
EX9200-6QS
“EX9200-MPC Line Card” on page 3A modular line card that accepts any of
the following MICs:
•
EX9200-10XS-MIC
•
EX9200-20F-M-MIC
•
EX9200-40T-MIC
EX9200-MPC
“EX9200-32XS Line Card” on page 27A line card with 32 10-Gigabit Ethernet
small form-factor pluggable plus (SFP+)
ports
EX9200-32XS
“EX9200-40T Line Card” on page 31A line card with 40 10/100/1000BASE-T
ports that support RJ-45 connectors
EX9200-40T
“EX9200-40F Line Card” on page 28A line card with 40 1-Gigabit Ethernet
small form-factor pluggable (SFP) ports
EX9200-40F
“EX9200-40F-M Line Card” on page 30A line card with 40 1-Gigabit Ethernet
small form-factor pluggable (SFP) ports
with Media Access Control Security
(MACsec) capability
EX9200-40F-M
Cooling System
The cooling system in an EX9204 switch is a field-replaceable unit (FRU). It consists of
a hot-removable and hot-insertable fan tray. The fan tray contains three fans. The fan
tray installs vertically on the right back of the chassis and provides side-to-side chassis
cooling. See Cooling System and Airflow in an EX9204 Switch.
Power Supplies
Power supplies for the EX9204 switch are fully redundant, load-sharing, and
hot-removable and hot-insertable FRUs. Each EX9204 switch chassis can hold up to
four AC or up to two DC power supplies.
Copyright © 2016, Juniper Networks, Inc.72
