You can use the show version command to see the version of Junos OS for EX Series
switches loaded on the switch.
Line Card Components
The EX9200-6QS line card has:
•
Six QSFP ports, each of which can house QSFP+ transceivers. These ports support
40GBASE-LR4 and 40GBASE-SR4 transceivers. Starting with Junos OS for EX Series
switches, Release 15.1 R3, these ports support the JNP-QSFP-40G-LX4 transceiver.
•
24 SFP+ ports, each of which can house SFP+ transceivers. These ports support
10GBASE-SR, 10GBASE-LR, 10GBASE-ER, and 10GBASE-ZR transceivers.
•
Line card LED—An LED labeled OK/FAIL indicates the status of the line card. See Line
Card LED in an EX9200 Switch.
•
Network port LED—One LED on each network port indicates the link activity of the port.
See “Network Port LEDs in an EX9200 Switch” on page 15.
The ports are divided into two port groups. The six 40-Gigabit Ethernet QSFP+ ports
labeled 2/0 through 2/2 and 3/0 through 3/2 form one port group. The twenty-four
10-Gigabit Ethernet SFP+ ports labeled 0/0 through 0/11 and 1/0 through 1/11 form the
other port group. The ports in each group share 240 gigabits of bandwidth. Thus, you can
transmit up to 240 gigabits of traffic through a port group, without packet drop.
Related
Documentation
Line Card Model and Version Compatibility in an EX9200 Switch on page 35•
• Pluggable Transceivers Supported on EX9200 Switches on page 37
• Installing a Line Card in an EX9200 Switch
• Handling and Storing Line Cards in EX9200 Switches
• Troubleshooting Traffic Drops on EX9200-6QS Line Cards
Line Card Model and Version Compatibility in an EX9200 Switch
Table 20 on page 35 shows the model numbers, description of the line card, and the
Junos OS release in which the line card was first supported.
Table 20: Line Card Models for EX9200 Switches
First Junos OS ReleaseDescriptionModel number
13.2R1A line card with two 100-Gigabit Ethernet
C form-factor pluggable (CFP) ports and
eight 10-Gigabit Ethernet small
form-factor pluggable plus (SFP+) ports
See “EX9200-2C-8XS Line Card” on
page 25
EX9200-2C-8XS
35Copyright © 2016, Juniper Networks, Inc.
