EX9200-40T-MIC has 40 RJ-45 ports, which can accept RJ-45 connectors. The
ports are divided into three port groups. The ports labeled 0/1 through 1/5 and 0/0
through 1/4 form port group pic0, the ports labeled 1/7 through 2/3 and 1/6 through
2/2 form port group pic1, and the ports labeled 2/5 through 3/9 and 2/4 through 3/8
form port group pic2. See Figure 4 on page 5.
•
Blank panels—Two blank panels that cover the MIC slots.
•
Line card LED—An LED labeled OK/FAIL indicates the status of the line card. See Line
Card LED in an EX9200 Switch.
•
MIC LED—An LED labeled OK/FAIL on each MIC indicates the status of the MIC. See
“Modular Interface Card LED in an EX9200 Switch” on page 5.
•
Network port LEDs—Each SFP+ port on the EX9200-10XS-MIC and each SFP port on
the EX9200-20F-M-MIC has an LED that indicates the link activity of the port. Each
10/100/1000BASE-T RJ-45 Ethernet network port on tEX9200-40T-MIC has two LEDs
that indicate link activity and status of each port. See “Network Port LEDs in an EX9200
Switch” on page 15.
Related
Documentation
Line Card Model and Version Compatibility in an EX9200 Switch on page 35•
• Pluggable Transceivers Supported on EX9200 Switches on page 37
• Installing a Line Card in an EX9200 Switch
• Installing a MIC in an EX9200-MPC Line Card on page 6
• Handling and Storing Line Cards in EX9200 Switches
Modular Interface Card LED in an EX9200 Switch
The Modular Interface Cards (MICs) in the following line cards for EX9200 switches have
an LED labeled OK/FAIL on the faceplate that indicates the online status information of
MICs.
•
EX9200-4QS Line Card on page 32
•
EX9200-MPC Line Card on page 3
•
EX9200-40F Line Card on page 28
•
EX9200-40F-M Line Card on page 30
•
EX9200-40T Line Card on page 31
Table 4 on page 6 describes the LED on line cards for EX9200 switches, its colors and
state, and the status it indicates.
5Copyright © 2016, Juniper Networks, Inc.
