Table 30 on page 73 shows the details of the power supplies available for EX9204
switches.
Table 30: Power Supplies Supported on EX9204 Switches
Output PowerInput VoltagePower Supply
1027 WLow-voltage line (100–120 VAC)2520 W AC
1590 WHigh-voltage line (200–240 VAC)
2400 W to 2600 W–40 VDC through –70 VDC2400 W DC
A base-configuration EX9204 switch ships with two low-line (100–120 VAC) AC power
supplies or one high-line (200–240 VAC) AC power supply. An AC-powered,
redundant-configuration EX9204 switch ships with four low-line (100–120 VAC) or two
high-line (200–240 VAC) AC power supplies. See AC Power Supply in an EX9204 Switch.
A DC-powered, redundant-configuration EX9204 switch ships with two DC power supplies.
See DC Power Supply in an EX9204 Switch.
CAUTION: Do not mix AC and DC power supplies in the same chassis.
Related
Documentation
Connecting and Configuring an EX9200 Switch (CLI Procedure)•
• Field-Replaceable Units in an EX9200 Switch
• Line Card Model and Version Compatibility in an EX9200 Switch on page 35
Chassis Physical Specifications of an EX9204 Switch
The EX9204 switch chassis is a rigid sheet-metal structure that houses the other switch
components. Table 31 on page 73 summarizes the physical specifications of the EX9204
switch chassis. See Figure 26 on page 75, Figure 27 on page 75, Figure 28 on page 76, and
Figure 29 on page 76.
Table 31: Physical Specifications of the EX9204 Switch Chassis
DepthWidthHeightWeightDescription
24.5 in. (62.2 cm) (from
front to chassis rear)
17.5 in. (44.5 cm)8.7 in. (22.1 cm)Chassis with midplane,
craft interface
(front-panel display),
fan tray, and air filter:
52.0 lb (23.6 kg)
Maximum configuration:
128.0 lb (58.1 kg)
Chassis
7.75 in. (19.7 cm)11 in. (27.9 cm)1.25 in. (3.2 cm)2.4 lb (1.09 kg)Routing Engine
module
73Copyright © 2016, Juniper Networks, Inc.
Chapter 3: Updated EX9204 Topics
