Line Card Components
The EX9200-40F-M line card has:
•
40 SFP MACsec-capable ports, each of which can house SFP transceivers. These ports
support 1000BASE-T, 10/100/1000BASE-T, 100BASE-FX, 1000BASE-EX,
1000BASE-LH, 1000BASE-LX, and 1000BASE-SX transceivers.
•
Line card LED—An LED labeled OK/FAIL indicates the status of the line card. See Line
Card LED in an EX9200 Switch.
•
MIC LED—An LED labeled OK/FAIL on each MIC indicates the status of the MIC. See
“Modular Interface Card LED in an EX9200 Switch” on page 5.
•
Network port LED—One LED on each network port indicates the link activity of the port.
See “Network Port LEDs in an EX9200 Switch” on page 15.
Related
Documentation
Line Card Model and Version Compatibility in an EX9200 Switch on page 35•
• Pluggable Transceivers Supported on EX9200 Switches on page 37
• Installing a Line Card in an EX9200 Switch
• Handling and Storing Line Cards in EX9200 Switches
EX9200-40T Line Card
The line cards in EX9200 switches provide packet forwarding services. They are
field-replaceable units (FRUs) that you can install in the line card slots on the front of
the switch chassis. Line cards are hot-insertable and hot-removable: You can remove
and replace them without powering off the switch or disrupting switch functions.
This topic describes:
•
Line Card Models on page 31
•
Line Card Components on page 32
Line Card Models
Table 17 on page 31 shows the model number, description of the line card model, and
the Junos OS release in which the line card was first supported.
Table 17: EX9200-40T Line Card
Junos OS Release RequiredDescriptionModel
12.3R2 or laterA line card with 40 10/100/1000BASE-T
ports that support RJ-45 connectors
EX9200-40T
See Figure 19 on page 32.
31Copyright © 2016, Juniper Networks, Inc.
Chapter 2: Updated Common EX9200 Topics
