The Status LED in 10/100/1000BASE-T RJ-45 Ethernet network port indicates the status
of one of the three port parameters. The port parameters are administrative status, speed,
and duplex mode status.
Table 6 on page 16 describes the Status LED.
Table 6: Network Port LEDs on Line Cards in an EX9200 Switch—Status
LED
State, Color, and DescriptionLCD IndicatorLED
Indicates the administrative status (enabled or
disabled). The status indicators are:
•
Green—Administrative status enabled.
•
Yellow—The port is down.
•
Unlit—Administrative status disabled.
LED: ADMStatus
Indicates the speed. The speed indicators are
different in the line cards.
LED: SPD
•
Unlit—10 Mbps
•
Green—Blinking—100 Mbps
•
Green—On steadily—1000 Mbps
Indicates the duplex mode. The status
indicators are:
•
Green—Port is set to full-duplex mode.
•
Unlit—Port is not set to full-duplex mode.
LED: DPX
Related
Documentation
Line Card LED in an EX9200 Switch•
• Craft Interface in an EX9200 Switch on page 20
Compliance Statements for EMC Requirements for EX Series Switches
This topic applies to hardware devices in the EX Series product family, which includes
EX Series switches, the EX Series Redundant Power System (RPS), and the XRE200
External Routing Engine.
This topic describes the EMC requirements for these hardware devices for:
•
Canada on page 17
•
European Community on page 17
•
Israel on page 17
•
Japan on page 18
•
Korea on page 18
•
United States on page 18
Copyright © 2016, Juniper Networks, Inc.16
Hardware Topics for Aloha Line Card
