You must install either two or three host subsystems in the slots 7 through 9—labeled 0,
1 and 2 | 6—in the front panel of the chassis. A base-configuration EX9214 switch has two
host subsystems. A redundant-configuration EX9214 switch has a third host subsystem.
For more information, see EX9214 Switch Configurations.
Line Cards
The EX9214 switch has 12 vertical line card slots. The line cards for EX9214 switches
combine a Packet Forwarding Engine and Ethernet interfaces in a single assembly. Line
cards are field-replaceable units (FRUs) that you can install in the line card slots 1 through
6 (labeled 0 through 5) and 9 through 14 (labeled 6 through 11) on the front of the switch
chassis. All line cards are hot-removable and hot-insertable. You can install a line card
or a host subsystem in slot 9—labeled 2 | 6.
Table 37 on page 94 lists the line cards available for EX9214 switches.
Table 37: Line Cards for EX9214 Switches
Additional InformationDescriptionModel
“EX9200-2C-8XS Line Card” on page 25A line card with two 100-Gigabit
Ethernet C form-factor pluggable (CFP)
ports and eight 10-Gigabit Ethernet
small form-factor pluggable plus (SFP+)
ports
EX9200-2C-8XS
“EX9200-4QS Line Card” on page 32A line card with four 40-Gigabit Ethernet
quad small form-factor pluggable plus
(QSFP+) ports
EX9200-4QS
“EX9200-6QS Line Card” on page 34A line card with six 40-Gigabit Ethernet
quad small form-factor pluggable plus
(QSFP+) ports and 24 10-Gigabit
Ethernet small form-factor pluggable
plus (SFP+) ports
EX9200-6QS
“EX9200-MPC Line Card” on page 3A modular line card that accepts any of
the following MICs:
•
EX9200-10XS-MIC
•
EX9200-20F-M-MIC
•
EX9200-40T-MIC
EX9200-MPC
“EX9200-32XS Line Card” on page 27A line card with 32 10-Gigabit Ethernet
small form-factor pluggable plus (SFP+)
ports
EX9200-32XS
“EX9200-40T Line Card” on page 31A line card with 40 10/100/1000BASE-T
ports that support RJ-45 connectors
EX9200-40T
“EX9200-40F Line Card” on page 28A line card with 40 1-Gigabit Ethernet
small form-factor pluggable (SFP) ports
EX9200-40F
