Juniper EX9200 User Manual

Table 25: Optical Interface Support for CFP Transceivers in EX9200 Switches (continued)
ValueSpecificationEthernet Standard
CFP-GEN2-100GBASE-LR4Model number100GBASE-LR4
Single-modeOptical interface
100 GbpsRate
IEEE 802.3ba-2010Standard
1294.53 nm through 1296.59 nm
1299.02 nm through 1301.09 nm
1303.54 nm through 1305.63 nm
1308.09 nm through 1310.19 nm
Transmitter wavelength
–4.3 dBm through 4.5 dBmAverage launch power
10.5 dBmMaximum launch power
–10.6 dBm through 4.5 dBmAverage receive power
4.5 dBmReceiver saturation
–10.6 dBmReceiver sensitivity
SMFFiber type
9/125 µmCore/Cladding size
10 km (6.2 miles)Distance
AvailableDOM support
Junos OS for EX Series switches, Release 13.2R1 or
later
Software required
Related
Documentation
Installing a Transceiver in a Switch•
• Removing a Transceiver from a Switch
• EX9200-2C-8XS Line Card on page 25
• EX9200-4QS Line Card on page 32
• EX9200-6QS Line Card on page 34
• EX9200-MPC Line Card on page 3
• EX9200-32XS Line Card on page 27
61Copyright © 2016, Juniper Networks, Inc.
Chapter 2: Updated Common EX9200 Topics
