Juniper SRX550 - Interface Module; Table 41: RS-422;449 DTE Cable Pinouts for the 1-Port Serial Mini-PIM; RS-422;449 (EIA-449) DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module

Table 40: RS-422/449 DCE Cable Pinouts for the 1-Port Serial
Mini-PIM (continued)
Description
LFH-60
Pairing
DC-37
(DB-37) PinLFH-60 Pin
Terminal Timing (B)5356
Send Common-3757
---26 to 25
Related
Documentation
EIA-530A DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 72
•
• RS-232 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on
page 74
• V.35 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 80
• X.21 DCE Cable Pinouts for the 1-Port Serial Mini-Physical Interface Module on page 82
RS-422/449 (EIA-449) DTE Cable Pinouts for the 1-Port Serial Mini-Physical Interface
Module
Table 41 on page 78 gives the RS-422/449 DTE cable pinouts.
Table 41: RS-422/449 DTE Cable Pinouts for the 1-Port Serial Mini-PIM
Description
LFH-60
Pairing
DC-37
(DB-37) PinLFH-60 Pin
Shield Ground-115
Send Data (A)59460
Send Timing (A)55556
Receive Data (A)261
Request to Send (A)47748
Receive Timing (A)685
Clear to Send (A)38937
Local Loopback-1041
Data Mode (A)10119
Terminal Ready (A)341233
Copyright © 2016, Juniper Networks, Inc.78
SRX550 High Memory Services Gateway Hardware Guide
