Juniper SRX550 - Connector Pinouts for the SRX550 High Memory Services Gateway Console Port; Console Port; Table 35: RJ-45 Connector Pinouts for the Services Gateway Console Port

Table 34: RJ-45 Connector Pinouts for Services Gateway Ethernet
Port (continued)
SignalPin
Termination network7
Termination network8
Related
Documentation
RJ-45 Connector Pinouts for the SRX550 High Memory Services Gateway Console
Port on page 71
•
• Interface Cabling and Wiring Specifications for the SRX550 High Memory Services
Gateway on page 69
RJ-45 Connector Pinouts for the SRX550 High Memory Services Gateway Console
Port
The port on the front panel labeled CONSOLE is an autosensing 10/100-Mbps Ethernet
RJ-45 receptacle that accepts an RJ-45 cable for connecting the services gateway to a
management LAN (or other device that supports out-of-band management).
Table 35 on page 71 describes the RJ-45 connector pinouts for the console port.
Table 35: RJ-45 Connector Pinouts for the Services Gateway Console
Port
DescriptionSignalPin
Request to SendRTS1
Data Terminal ReadyDTR2
Transmit DataTXD3
Signal GroundGround4
Signal GroundGround5
Receive DataRXD6
Data Set ReadyDSR/DCD7
Clear to SendCTS8
Related
Documentation
RJ-45 Connector Pinouts for the SRX550 High Memory Services Gateway Ethernet
Port on page 70
•
• Interface Cabling and Wiring Specifications for the SRX550 High Memory Services
Gateway on page 69
