Juniper SRX550 - Connector Pinouts for the SRX550 High Memory Services Gateway Ethernet Port; Ethernet Port; Table 33: Cable and Wire Specifications for Ports and Alarm Interfaces; Table 34: RJ-45 Connector Pinouts for Services Gateway Ethernet Port

Table 33: Cable and Wire Specifications for Ports and Alarm Interfaces
Device
Receptacle
Maximum
LengthCable/Wire Supplied
Cable
SpecificationPort
RJ-456 ft (1.83 m)One 6-ft (1.83-m) length
with DB-9/DB-9
connectors
RS-232 (EIA-232)
serial cable
Console
Mini-B USB
Socket
6 ft (1.83 m)One 6-ft (1.83-m) length
with Mini-B and Type A
plugs
USBUSB
console
RJ-45
autosensing
328 ft
(100 m)
One 15-ft (4.57-m) length
with RJ-45/RJ-45
connectors
Category 5 cable or
equivalent suitable
for 100Base-T
operation
Ethernet
NOTE: The Auxiliary port is not supported on the SRX550 High Memory
Services Gateway.
Related
Documentation
RJ-45 Connector Pinouts for the SRX550 High Memory Services Gateway Ethernet
Port on page 70
•
• RJ-45 Connector Pinouts for the SRX550 High Memory Services Gateway Console
Port on page 71
RJ-45 Connector Pinouts for the SRX550 High Memory Services Gateway Ethernet
Port
The port on the front panel labeled ETHERNET is an autosensing 10/100/1000-Mbps
Ethernet RJ-45 receptacle that accepts an Ethernet cable for connecting the services
gateway to a managementLAN (or other devicethat supports out-of-band management).
Table 34 on page 70 describes the RJ-45 connector pinouts for the Ethernet port.
Table 34: RJ-45 Connector Pinouts for Services Gateway Ethernet Port
SignalPin
TX+1
TX-2
RX+3
Termination network4
Termination network5
RX-6
Copyright © 2016, Juniper Networks, Inc.70
SRX550 High Memory Services Gateway Hardware Guide
