The 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM) provides the following key
features:
•
Channel service unit/data service unit (CSU/DSU) to eliminate the need for a separate
external device
•
56-Kbps and 64-Kbps operating modes
•
Independent internal and external clocking option
•
Alarm reporting with a 24-hour history maintained
•
Loopback, BERT, FDL (T1 only), and Long Buildout (T1 only) diagnostics
•
Multilink Frame Relay and Multilink PPP support
The 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM) supports the following
standards:
•
ANSI TI.107, TI.102
•
GR 499-core, GR 253-core
•
AT&T Pub 54014
•
ITU G.751, G.703
1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R) Hardware Specifications
Table 20 on page 35 gives the physical specifications of the 1-Port T1/E1 Mini-Physical
Interface Module (Mini-PIM).
Table 20: 1-Port T1/E1 Mini-PIM (SRX-MP-1T1E1-R) Physical Specifications
ValueDescription
0.80 in. x 3.75 in. x 5.9 in.
(2.0 cm x 9.5 cm x 14.5 cm )
Dimensions (H x W x L)
2.88 oz (82 g)Weight
RJ-48Connector type
Mini-PIMForm factor
32°F through 104°F (0°C through 40°C)Environmental operating temperature
–40°F through 158°F (–40°C through 70°C)Storage temperature
5% to 90% noncondensingRelative humidity
1-Port T1/E1 Mini-Physical Interface Module (SRX-MP-1T1E1-R) LEDs
The 1-Port T1/E1 Mini-Physical Interface Module (Mini-PIM) has three LEDs.
Table 21 on page 36 describes the LED states.
