KEEWAY RKV125 User Manual

* Attention:
Hammered-out bearing cannot be reused. Replace it with a
new one.
Remove bearing and oil seal with special tools.
Remove bearing on right crankcase.
Check if bearing is injured. Replace if necessary.
* Attention:
Hammered-out bearing cannot be reused. Replace it with a
new one.
Remove bearing and oil seal with special tools.
Main shaft and countershaft combination
* Attention: Apply each gear and shaft with lubricating grease evenly at combination.
Make sure there is no stuck after combination.
Note:
Install the crankcase in the reverse order of removal.
Bearing hole, oil seal hole

KEEWAY RKV125 Specifications

General

Engine Type	Single cylinder, 4-stroke, air-cooled
Fuel System	Carburetor
Transmission	5-speed
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Cooling System	Air-cooled
Seat Height	770 mm
Weight	135 kg
Fuel Tank Capacity	17 L
Rear Suspension	Dual shock absorbers
