II Ignition System
Preparatory data-------------------2.1 CDI assembly--------------2.4
Fault diagnosis--------------------2.2 Ignition coil----------------2.5
Ignition system inspection-------2.3 Trigger----------------------2.6
2.1 Preparatory Data
Precautions on operation
1. Ignition system inspection: please perform inspection in the sequence listed in the fault diagnosis table.
2. Ignition system uses electronic-type automatic timing device, which is solidified in the CDI assembly, so it is
unnecessary to adjust the ignition time.
3. Ignition system inspection: please perform inspection in accordance with the sequence listed in the fault diagnosis
table.
4. Ignition system CDI shall not be dropped and hung, or heavily knocked (this is also the main reason for its failure).
Pay special attention to this while removing it.
5. Most of the ignition system problem due to poor contact of sockets. Please check first if parts of the connector are
well contacted.
6. Check if heat value of spark plug is proper. Improper spark plug may result in unsmooth engine running or burn of
spark plug.
7. The maximum voltage is taken to introduce inspection items in this Part. Inspection methods for impedance value
of ignition coil are also recorded and judged.
8. Check ignition switch according to the continuity test table.
9. Remove magneto and stator on operation instructions.
Preparatory data
