Attention
Do not damage exterior parts during disassembly and assembly.
Do not damage the pawls on the exterior parts of the vehicle during assembly or disassembly.
Align built-in panel and cover plate to their grooves respectively.
Correctly install jaw of each part during combination.
Do not damage the fittings during exterior part installation.
1 Right cowling installation plate 2 Cowling installation plate 3 Left cowling installation plate 4 Right decorative
panel II 5 Right decorative panel I 6 Left decorative panel I 7 Left decorative panel II 8 Right tail cover
9 Left tail cover 10 Decorative panel for left protecting plate 11 Left protecting plate 12 Decorative panel for right
protecting plate 13 Right protecting plate 14 Tail cover bracket 15 Rear mudguard II 16 Rear mudguard I
17 Front part of rear mudguard II 18 Front part of rear mudguard 19 Left decorative panel for front mudguard
20 Right decorative panel for front mudguard 21 Front mudguard
